Self Fusing PIB Self Amalgamating Tape

FOB Reference Price:Get Latest Price
$0.30 - $3.00 / Rolls | 1 Roll/Rolls (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Product name:
PIB Self Amalgamating Tape
Color:
Black
Width:
19mm, 25mm, 45mm, 50mm,
Thickness:
0.076mm
Length:
9.14m, 5m
Usage:
Winding pipe
Certificates:
ISO9001
Type:
rubber self-fusing tape
Supply Ability
Supply Ability:
1000000000 Roll/Rolls per Week
Packaging & Delivery
Packaging Details
carton
Port
tianjin
Video Description
Product Description

Product Application

This tape is a self amalgamating , low voltage rubber tape which meets the requirements of ASTM-D-4388,Type I, It easily conforms to irregular shapes and surfaces yielding a void free, electrically stable build up. Compatabile with all extruded dielectric cable insulation.
Property
Value
Unit
Text Method
Total thickness
0.76
mm
ASTM-D-4325
tensile strength
250
psi
ASTM-D-4325
Elongation at break
400
%
ASTM-D-4325
contiouous Operation Temperature
80
ASTM-D-4325
Emergency Overload Temperature
95
ASTM-D-4325
Dieletric
20
KV/mm
ASTM-D-4325


Date in table represent average text results are not be used for specification purpose.

Standard sizes
thickness
width
length
0.5mm
19mm
9m
0.76mm
19mm
9m
0.76mm
25mm
9m
0.76mm
38mm
9m

other size and corse are available customization.

Recommend Uses

For insulating of splices on solid dielectric cable from 2KV to 10KV in conjunction with a jacket tape.
